355320563mm Premium Anti-Static PCB Storage Rack

Product Overview

PCB Rack 355×320×563 mm It is an optimized solution for factories and production lines in the electronics, SMT, and cleanroom industries. The product is specially designed for the safe storage, transportation, and protection of printed circuit boards (PCBs), preventing damage caused by impact, dust, or electrostatic discharge. With a standard size of 355×320×563 mm, the PCB rack provides convenience, organization, and a professional appearance for any workspace.

Product Description: PCB Rack

• Product NamePCB Rack

• Dimensions: 355×320×563mm

• ModelCustomizable according to customer requirements or manufacturer specifications.

• Main MaterialAluminum profile / Stainless steel (Inox) / Premium ESD-safe plastic.

• ColorCommonly available in black or gray ESD-safe colors, with customizable colors upon request.

• WeightLightweight and easy to move while maintaining excellent structural stability.

The PCB rack is manufactured in compliance with cleanroom and ESD standards, suitable for both large-scale industrial production and individual workstation use. The materials are carefully selected for durability, high load-bearing capacity, and long-term resistance to corrosion.

Versatile Applications of PCB Rack 355×320×563 mm

The PCB rack 355×320×563 mm is widely used in various manufacturing and research environments, particularly in:

1. Cleanrooms for manufacturing electronic components, semiconductors, and SMT circuit boards

   • Used for storing circuit boards during assembly, inspection, or packaging processes.

2. Pharmaceutical, cosmetic, and medical device factories

   • Used for storing control boards, electrical circuits, or components used in production machinery.

3. Laboratories (Labs), hospitals, research centers

   • Used for storing circuit boards for laboratory equipment, analyzers, and diagnostic machines.

4. Electrostatic Protected Areas (EPA Zones)

   • Ensures ESD safety and prevents component damage caused by electrostatic discharge.

5. Used for individuals, workstations, or production lines

   • Helps organize circuit boards neatly, facilitates easy management, and optimizes workspace utilization.

Product Benefits Printed Circuit Board (PCB)

The product is not just a simple rack — it also offers numerous outstanding advantages:

• Increase productivity and production efficiency
  Scientific board arrangement enables faster operation, saving time in locating and transferring circuit boards.

• Ensures product safety and quality.
  Anti-static and scratch-resistant, minimizing the risk of PCB damage.

• Minimizes issues caused by dust contamination or cross-contamination.
  Stores circuit boards in a clean environment, minimizing dust and bacterial contamination.

• Helps enterprises meet international standards.
  Meets the requirements of ISO, ESD, GMP, supporting inspection and production certification.

• Long-term cost savings
  High durability with minimal failures, reducing replacement and maintenance costs.

Product structure and design

The PCB rack 355×320×563 mm is designed with a perfect combination of engineering precision and aesthetic appeal:

• Sturdy and modern design.
  The rack frame is made of aluminum profile or stainless steel (Inox) Corrosion-resistant, with excellent load-bearing capacity, ensuring long-term durability.

• Cleanroom-grade materials
  Use ESD-safe plastic or anti-static carbon fabric at contact points to protect sensitive electronic components.

• Key Features

  • Corrosion-resistant and scratch-resistant.

  • Easy to clean and maintain.

  • The PCB tray features standard grooves that securely hold the circuit boards in place without shifting.

  • Optimized storage design allows multiple racks to be stacked for efficient space utilization.

• Upgrade Options
  Optional designs include adding wheels, dust covers, or customized dimensions to meet customer requirements.

Instructions for use and precautions

Installation method:

1. Assemble the main frame according to the accompanying technical diagram.

2. Install the trays or PCB support bars in their corresponding positions.

3. Tighten all screws to ensure structural stability.

Operation Method:

• Arrange the circuit boards in order, avoiding excessive stacking that may cause warping.

• Move gently when using wheels; do not drag the rack.

Regular Maintenance:

• Clean with a soft cloth and a cleanroom-approved cleaning solution.

• Regularly inspect all screws and joints.

Note:

• Do not use in humid or high-temperature environments.

• Avoid strong impacts or improper use.
